M12 x 180mm Carriage Bolt

A heavy steel washer, for general use with bolts and threaded bar (studding).
BZP (Bright Zinc Plate) finish.

Dimensions: 2mm x 28mm Diameter
13mm Bolt Hole: To suit M12 thread

Galvanised Truss Clip for constructing timber to timber framework. Precision formed and engineered for fast installation and maximum loads.

- Suitable for securing 47mm wide timber
- Overall Width - 105mm (including fixing wings)
- Length - 100mm

Install using 3.75 x 30mm square twist nails
12 nail holes / truss clip
1kg square twist nails installs approx. 29 truss clips

Carriage Bolt; cup square hex, 30mm mushroom head, BZP finish (Bright Zinc Plate). Designed for bolting through timber.

Square hex refers to the square section attached to the mushroom head, this sinks into timber and stops the bolt from spinning when the nut is tightened.

Supplied with one standard hex nut, washers sold separately.

A heavy steel washer, for general use with bolts and threaded bar (studding).
BZP (Bright Zinc Plate) finish.

Dimensions: 2mm x 24mm Diameter
11mm Bolt Hole: To suit M10 thread

Planed decking newel post with 2 grooves machined at the top.

- Planed from 100 x 100mm, finished size approx. 95 x 95mm
- Good quality slow-grown softwood
- Planed finish, with rounded corners
- Pressure treated green UC4

A self tapping bolt suitable for concrete, stone, brick, marble, wood and block (solid or hollow). Safe anchorage achieved without the need of high tightening forces. Can be removed and re-fixed into the same hole, providing the thread is correctly aligned. No expansion forces enables close to the edge fixing.

Drill Bit Dia. - 8mm
Anchor Length - 75mm
Washer Size - 10mm (M10)
Min Hole Depth - 55mm
Min Over Drill Depth - 15mm
Min. Embed Depth - 40mm
Max. Fixture Thickness - 35mm
Drill Bit Dia. for clearance - 10mm (to prevent binding when tightening bolt)
Head Type - Hex Head, 15mm (Across Flats)
Driver Type - Impact driver, socket, spanner
Max Tightening Torque - 40Nm
