Impact Socket Adaptor Set - 3 Pce

125mm Feather Edge Boards are tapered boards that are vertically lapped to form a solid fence.
Feather-edge can also be fitted horizontally as a budget cladding.

- 125mm Board Width
- 10 boards needed per linear metre (25mm overlap)
- Cut from 22 x 125mm
- Finished size approx. 12mm on thick edge tapering to 6mm on thin edge
- Homegrown Spruce
- Sawn finish
- Pressure treated green

A self tapping bolt suitable for concrete, stone, brick, marble, wood and block (solid or hollow). Safe anchorage achieved without the need of high tightening forces. Can be removed and re-fixed into the same hole, providing the thread is correctly aligned. No expansion forces enables close to the edge fixing.

Drill Bit Dia. - 8mm
Anchor Length - 75mm
Washer Size - 10mm (M10)
Min Hole Depth - 55mm
Min Over Drill Depth - 15mm
Min. Embed Depth - 40mm
Max. Fixture Thickness - 35mm
Drill Bit Dia. for clearance - 10mm (to prevent binding when tightening bolt)
Head Type - Hex Head, 15mm (Across Flats)
Driver Type - Impact driver, socket, spanner
Max Tightening Torque - 40Nm

A heavy steel washer, for general use with bolts and threaded bar (studding).
BZP (Bright Zinc Plate) finish.

Dimensions: 2mm x 24mm Diameter
11mm Bolt Hole: To suit M10 thread

Galvanised steel bracket for attaching 75mm triangular Arris Rail to square posts or wall plates. Minimum post/wall plate width is 45mm.

Angle: 62 x 62mm (suits 75mm Arris Rail)
Wings: 42 x 155mm (overall width)
Length: 285mm
Fixing Holes: (10x) 5mm diameter + (2x) 27mm x 6mm slots

This post support is designed to hold a 100 x 100mm square wooden post in position when it’s not possible to concrete a post into the ground. The metal fins inside of the post support wedge into the timber ensuring a quick and secure fit.

- Designed to fit 100 x 100mm square wooden posts
- Fin-Grip post securing system
- Bolt down plate: 170mm x 170mm
- Bolt holes: 4 x 12mm Ø holes for bolting down the base (approx. 135mm hole centres)
- Manufactured from 2mm thick steel
- Welded construction
- Galvanised finish for durability outdoors

Arris rail is a triangular shaped fencing rail for use with feather edge fencing. This rail is designed to fit into notched posts or can be attached to standard posts with an arris rail bracket. Arris rail can also be used (under felt) around the edges of flat roofing, or as corner reinforcement when building wooden crates etc.

- Cut from 75 x 75mm (Square)
- Rail Dimensions: 74 x 74mm x 2.4m, 105mm on longest edge
- Sawn Finish
- Homegrown Softwood, locally produced in the UK
- Pressure Treated - Green
