Corner Profile - Treated Softwood

A contemporary open tongue and grooved profile, also known as shadow gap.
A heavy duty cladding used to make gates, doors, sheds & other garden structures.
Produced from high quality redwood and pressure treated for durability outdoors.

- PTGV Profile (Planed Tongue & Groove, open 'V'-joint)
- Machined from: 25 x 150mm
- Finished thickness: 20mm
- Board coverage when fitted: 125mm
- High quality, slow grown redwood
- Pressure Treated (green), 15 year performance warranty - view the Downloads tab below for details
- This cladding product is CladMark accredited.
- This profile can be installed vertically and horizontally
- 8 linear metres needed to cover 1m²

125mm Feather Edge Boards are tapered boards that are vertically lapped to form a solid fence.
Feather-edge can also be fitted horizontally as a budget cladding.

- 125mm Board Width
- 10 boards needed per linear metre (25mm overlap)
- Cut from 22 x 125mm
- Finished size approx. 12mm on thick edge tapering to 6mm on thin edge
- Homegrown Spruce
- Sawn finish
- Pressure treated green

A traditional style of treated softwood cladding that suits every budget. This is a popular cladding for larger agricultural barns, sheds and stables due to the economical price. Feather Board cladding is good quality cladding suitable for many cladding projects.

- Sawn Finish, Feather Board Profile (with 25mm rebated back edge)
- Machined from: 32 x 175mm (two boards cut diagonally from this size)
- Fitted Thickness: 20mm tapering to 10mm approx.
- Fitted Coverage: 150mm
- High quality, slow grown redwood
- Pressure Treated (green), 15 year performance warranty - view the Downloads tab below for details
- This cladding product is CladMark accredited.
- This Feather Board cladding is rebated on the back for quick & easy installation
- We recommend this profile is installed horizontally
- 6.67 linear metres are needed to cover 1m²

19 x 125mm Shiplap is popular cladding often used by shed manufacturers to build heavier duty structures such as garden workshops, premium quality sheds, summerhouses, bike stores etc.

- Machined from: 19 x 125mm
- Finished Thickness: 14mm
- Fitted Coverage: 105mm
- High quality, slow grown redwood
- Pressure Treated (green), 15 year performance warranty - view the Downloads tab below for details
- This cladding product is CladMark accredited.
- We recommend this profile is installed horizontally
- 9.52 linear metres are needed to cover 1m²

A heavy duty treated softwood cladding often used to build sheds & other garden structures. Produced from good quality redwood and pressure treated (Green) for outdoor durability.

- Machined from: 25 x 150mm
- Finished thickness: 20mm
- Board coverage when fitted: 120mm
- High quality, slow grown redwood
- Pressure Treated (green), 15 year performance warranty - view the Downloads tab below for details
- This cladding product is CladMark accredited.
- We recommend this profile is installed horizontally
- 8.33 linear metres are needed to cover 1m²

A popular treated softwood T&G cladding with many uses: making gates, doors, sheds & other garden structures, cladding to cover old brickwork, premium fencing etc.
Produced from good quality redwood and pressure treated (Green) for outdoor durability.

- PTGV Profile (Planed Tongue & Groove, with a 'V' joint)
- Machined from: 19 x 100mm
- Finished thickness: 14mm
- Board coverage when fitted: 85mm
- High quality, slow grown redwood
- Pressure Treated (green), 15 year performance warranty - view the Downloads tab below for details
- This cladding product is CladMark accredited.
- We recommend this profile is installed vertically
- 11.76 linear metres are needed to cover 1m²
