100mm Corner Brace

Premium quality planed finish Picket Slats. Machined from 22 x 75mm joinery grade Scandinavian redwood, pressure treated green with a 15 year guarantee. Picket Slats are sold individually; build the fence to your own specification.

- Dimensions: 20 x 70 x 900mm (finished sizes)
- Round Top
- Planed all round
- Premium Quality Scandinavian Redwood
- Pressure treated with 15 Year Guarantee - details in downloads tab below

If you would like help to calculate the materials you need, please give us a call 0117 9674382.

Softwood sleeper, pressure treated green, sawn finish, non-structural timber. Mainly used for landscaping projects; for raised beds and retaining walls but could have many other uses.

- Dimensions: 100 x 200mm x 2.4m
- Sawn Finish
- Homegrown Softwood, locally produced in the UK
- Pressure Treated - Green

125mm Feather Edge Boards are tapered boards that are vertically lapped to form a solid fence.
Feather-edge can also be fitted horizontally as a budget cladding.

- 125mm Board Width
- 10 boards needed per linear metre (25mm overlap)
- Cut from 22 x 125mm
- Finished size approx. 12mm on thick edge tapering to 6mm on thin edge
- Homegrown Spruce
- Sawn finish
- Pressure treated green

125mm Feather Edge Boards are tapered boards that are vertically lapped to form a solid fence.
Feather-edge can also be fitted horizontally as a budget cladding.

- 125mm Board Width
- 10 boards needed per linear metre (25mm overlap)
- Cut from 22 x 125mm
- Finished size approx. 12mm on thick edge tapering to 6mm on thin edge
- Homegrown Spruce
- Sawn finish
- Pressure treated green

A self tapping bolt suitable for concrete, stone, brick, marble, wood and block (solid or hollow). Safe anchorage achieved without the need of high tightening forces. Can be removed and re-fixed into the same hole, providing the thread is correctly aligned. No expansion forces enables close to the edge fixing.

Drill Bit Dia. - 8mm
Anchor Length - 75mm
Washer Size - 10mm (M10)
Min Hole Depth - 55mm
Min Over Drill Depth - 15mm
Min. Embed Depth - 40mm
Max. Fixture Thickness - 35mm
Drill Bit Dia. for clearance - 10mm (to prevent binding when tightening bolt)
Head Type - Hex Head, 15mm (Across Flats)
Driver Type - Impact driver, socket, spanner
Max Tightening Torque - 40Nm

A mild steel plate with fixing holes used for strengthening and repairs.
Pre-drilled fixing holes for use with countersunk screws. Bright Zinc Plated (BZP) for corrosion resistance.

Thickness: 2.0mm
Width: 19mm
Length: 100mm
Fixing Holes: 5.0mm (x4)
